The BC Series is highly accurate single point load cell. It is ideal for OEM applications such as electronic scales and weighing machines. The single point design is highly resistant to eccentric loading allowing direct mounting to the scale base and weighing platform.
[twocol_one]Features:
[/twocol_one] [twocol_one_last]Application:
[/twocol_one_last] [twocol_one]- Off Center Compensated
- Protection Class IP65
- Material: Aluminum
- Bench Platform
- Checker
- Bagging
- Filling and Grading Machines
Specifications:
| Max Capacity (rated load) | kgf | 30,60,100,150kg |
| Rated Output Zero Balance |
mv/v mv/v |
1.2 approx 0.0 ± 0.06 |
| Accuracy Class | – | – |
| Non-Linearity Hysteresis Combined Error Repeatability Creep for 30min Return for 30min Resolution Division |
%RO %RO %RO %RO %RO %RO – mV/V |
0.03 0.03 0.03 0.01 0.03 0.03 ≤1/3000 0.0004 |
| Temperture Effect On Zero Value Output Value |
%/10°C %/10°C |
0.028 0.015 |
| Excitation Recommended Maximum |
V V |
– 10 15 |
| Resistance Input Output Insulation |
– Ω Ω MΩ |
– 420 ± 20 350 ± 3.5 >2000 |
| Compensated Temperture Range Operating Temperture Range |
°C °C |
-10 to +40 -20 to +70 |
| Material & Plate | – | Anodised Aluminium |
| Cable Specification | – | ø5 x 4p x 30cm (P.V.C) |
| Safety Overload | %RL | 150%RL |
| Platform Size | mm | 400 x 400 |
